Diesel generator ATS is an "automatic switching system", which is a device (cabinet) that controls the switching between the mains power and the generator.
It is powered by the mains power during normal operation, and automatically or manually switches to the generator power supply after
the mains power is interrupted! The usual and simple method is to use a rotary switch to select automatic, manual, or remote control unit communication devices.
The ATS cabinet is suitable for a variety of power systems, especially places with strict requirements for power outages, such as hospitals, data centers, financial institutions, etc.
In these places, the stability of power supply is crucial to ensure normal operation. TheATS cabinet can realize the unattended function.
When the mains power returns to normal, it will automatically switch back to the mains power supply and delay
the stop of the generator set, thereby achieving rapid recovery of the power supply system.
Advantages And Characteristics
Automated operation:
The ATS control panel can automatically detect the power status and switch to the backup power supply
in case of a main power failure, without the need for manual intervention.
Intelligent control:
Modern ATS control panels integrate intelligent control systems, which can achieve functions
such as delay, voltage and current display, and manual control.
Remote monitoring:
Supports remote monitoring function, which can be controlled and managed remotely
through communication interfaces and monitoring protocols.
Strong safety:
It has reliable mechanical and electrical interlocking functions, ensuring that only one position
is connected to prevent short circuits and equipment damage.
Dual power input:
ATS control panels are typically designed with dual power inputs,
with one main power source and the other backup power source.
Manual/Automatic Mode:
Provides two operating modes, manual and automatic,
which users can choose according to their needs.
Product Details
The ATS cabinet is mainly composed of an intelligent controller and a high-performance dual-power automatic switching switch.
When the mains power is out or a fault occurs (such as phase loss, undervoltage, loss of voltage or frequency deviation, etc.),
the ATS cabinet can automatically detect and issue an action command to enable the switch body to quickly switch from one
power supply to another to ensure continuous and reliable operation of important loads.
The panel displays the voltage and current of the two power supplies. Frequency, power and other electrical quantities,
and also displays the power supply status of the two power supplies. Through the control module setting,
it can be set on site to one power supply priority, two power supplies priority or no priority (i.e., mutual backup) power supply mode.
Product Parameter
| Parameter Name | Parameter Value |
| Rated Insulation Voltage (Ui) | 660V, 1000V |
| Rated Working Voltage (Ue) | Auxiliary - circuit: AC 220V, 380V; DC 110V, 220V |
| Rated Frequency (f) | 50Hz or 60Hz |
| Rated Current (In) | Horizontal bus - bar: ≤ 6300A；Vertical bus - bar: 1000A, 1600A, 2500A |
| Rated Short - Circuit Withstand Current (Icw, 1s) | 50kA, 65kA, 80kA, 100kA |
| Rated Peak Withstand Current (Ipk) | 105kA, 143kA, 176kA, 220kA |
| Rated Short - Circuit Breaking Current (Icu) | 50kA, 65kA, 80kA, 100kA |
| Parameter Name | Parameter Value |
| Protection Level | IP30, IP40, IP42, IP54, etc. (can be customized according to requirements) |
| Shell Material | Cold - rolled steel plate or stainless steel plate, and the thickness of the plate is generally not less than 1.2mm |
| Overall Dimensions (Width×Depth×Height, mm) | Standard cabinet: 800×800×2200, 1000×800×2200, 1200×800×2200, etc. (can be customized) |
| Number of Circuits in Drawer Unit |
1/4 - unit drawer: up to 22 circuits in a single cabinet 1/2 - unit drawer: up to 11 circuits in a single cabinet 1 - unit drawer: up to 6 circuits in a single cabinet 2 - unit drawer: up to 3 circuits in a single cabinet 3 - unit drawer: up to 2 circuits in a single cabinet |
| Drawer Interlock | It has mechanical and electrical interlocks to prevent misoperation |
| Drawer Unit |
The height modulus is 20mm, and the height of the drawer compartment can be divided into 1E, 2E, 3E, 4E, 5E, 6E, 8E, 10E, 12E, 16E, 20E, 24E, etc. (1E = 20mm, for example, the height of an 8E drawer is 160mm) |
If you are seeking a reliable solution for power distribution and control in an oil factory,
our ATS control panel is undoubtedly your best choice. Contact us immediately to learn more about our products,
obtain exclusive customized solutions, and work together to create a stable and efficient future of electricity.
Application areas
Power system:
In the power system, ATS control boxes are widely used in substations and distribution networks to
ensure rapid switching to backup power sources in the event of a main power failure,
ensuring the stable operation of the power grid.
Data Center:
Data centers are the core facilities of the information age, with extremely high requirements for the continuity and stability of power supply.
ATS cabinets can ensure seamless switching of data centers to backup power sources in the event of a power outage, protecting data from loss.
Medical equipment:
Medical equipment in hospitals and other medical institutions has strict requirements for power supply,
and any power interruption may lead to serious consequences. The ATS control panel plays a crucial role in these situations,
ensuring continuous power supply for critical medical equipment.
Industrial control system:
In automated production lines and industrial control systems, ATS panels can provide uninterrupted power support,
avoiding production interruptions and potential safety risks.
Communication facilities:
Communication base stations and network centers require 24-hour uninterrupted power supply,
and ATS control cabinets can ensure automatic switching to backup power in case of mains power failure,
ensuring the continuity of communication services.
Commercial buildings:
In large shopping malls, hotels, office buildings, and other commercial buildings, ATS control panels can ensure the power supply
of key facilities such as lighting, elevators, and security systems, enhancing the intelligence level of the building.
Transportation:
In transportation hubs such as airports, train stations, and subway stations, ATS control panels can ensure the power supply of critical systems,
such as signal systems and security equipment, to ensure the safety and efficiency of transportation.
